100 Gallons Marine Fuel Bladder

KEY BENEFITS

  • Carry extra fuel.
  • Carry extra water.
  • Custom-made for your needs.
  • Small, light, easy to transport.
  • Easy to fold and store when empty.
  • Quick filling from any standard refueling nozzle.
  • All materials are recyclable and reusable.

$1,290.00

In stock (can be backordered)

Buy Now

Secured Purchase

SKU: TGMB100TT Categories: ,

ABOUT OUR TANKS

Every time you get on your boat or yacht one of the very first things that comes to your mind is fuel. Whether you've planned a fun day filled with water sports activities, or you're heading out to the open ocean for some deep diving or fishing, or you are simply taking off on a long voyage, having reliable extra fuel is always beneficial. And that is why we created the Techno Tanks Marine Fuel Bladders.

Don't let an empty fuel tank spoil your fun and don't be a victim of bad quality fuel or ultra high fuel prices. Our bladders are manufactured with patented thermoplastic polyurethane with directional molecule technology that provides the optimum properties of flexibility, elasticity, and strength to withstand the most demanding conditions and they are designed to occupy minimal space when not in use as they can be easily stored in any compartment.

Because we care about your ship we manufacture in all white materials to reduce heat absorption and to match the color of most decks and because we care about our Planet, all bladders are made with materials that are 100% recyclable and reusable!

FEATURES

N

Manufactured in thermo polyester with military specs.

N

Patented state-of-the-art dual-action aluminum flanges with viton seals.

N

304 Stainless Steel Ball Valves.

N

Anti-cross threading system for easy fastening of loading cap.

N

Aluminum loading cap with proprietary anti-slip design.

N

Easy access to bronze pressure valve for quick gas release.

N

White matte finish reduces heat absorption and gas formation.

N

Designed to blend with most decks for pleasing aesthetics.

N

Shaped to minimize the footprint on your deck.

N

Easy to install, use and store.

N

Everything you need in one portable bag.

N

Fill it with air and use it as a flotation device.

LIQUID TYPES

\

Gasoline

\

Diesel

\
Bio-Diesel
\
Ethanol
\

Methanol

\

100LL Fuel

\
Lubricants
\

#2 and #4 Fuel Oil

\

Potable Water

Technical Specifications

1

CAPACITY

100 Gallons
379 Liters
.

DIMENSIONS EMPTY

24″ x 16″ x 8″
61 x 41 x 20 cm
0

DIMENSIONS FILLED

47″ x 35″ x 14.5″
120 x 90 x 37 cm

APPROXIMATE WEIGHT

15 LBS
7.5 KG

RESOURCES

How-to Install

Storage Guide

Technical Specifications

FREQUENTLY ASKED QUESTIONS

How resistant are Techno Tanks bladders?

They are extremely resistant as they are manufactured with military specs and materials. However, we recommend that all tanks be handled with care and respect, especially when filled with flammable fuels.

What sizes are available?

Sizes available are for 30, 60, 80, 100, 150, 200 & 250 gallons. Custom sizes and shapes are available on special order.

Can I connect my bladder tank directly to my engine?

The tanks can be connected directly to the engines as long as you are using the correct fittings and adapters.

Can I get every drop out of the bladder?

Almost all the fuel will be purged. You can aid the process by rolling the tank from the outside towards the outlet fitting.

How do I tie down the bladder?

Techno Tanks bladder tanks are best transported either full or empty. Empty bladders should be collapsed and stored in a vented locker. Full bladders can be tied down to the deck by using the rings located on the top of the tanks.

My tank is stable when fuel. Do I still need to tie i down?

Under most conditions, a full bladder tank will stay put, but in high seas (or turbulent air) bladders can become unstable and shift. With full weights of 150 lbs. to 3000 lbs., it is dangerous to use them if not fully restrained.

Can I mount my fuel bladder below deck?

Coast Guard regulations do not permit in-hull locations. We recommends securely lashing the full bladder above deck for better gravity fuel transfer, safer venting and ease of clean-up should any fuel be spilled during filling.

Do the fuel bladders suffer from weather exposure?

Yes, to some extent. Despite UV additives and hydrolysis stabilizers, rubber and fabric products can take a beating in extremes of sun, cold, dampness and abrasion.  When not in use, we recommend storing the drained bladder in a dry and vented locker.

Do you offer an electric fuel pump for transferring gasoline or diesel?

No, we recommends gravity or siphon flow, but Reverso and Jabsco can provide 12V and 24V diesel pumps with explosion-proof motors. Arnold offers a hand siphon pump.

Can I fill the bladder with fuel and carry it to my boat?

No. Full bladders are very hard to grasp and they weigh from 150 to 3000 lbs. We recommend filling them located were they will be used.

Will my bladder tank float if it falls overboard?

Yes, definitely! Fuel is 2/3 the density of water so it will always produce buoyancy. Also, in emergencies, an empty bladder can be lightly filled with air to provide significant buoyancy for personnel and the entire craft.
